Guitar Dyads: Double Stop Intervals

Guitar Dyads: Double Stop Intervals

If you play two notes at the same time then that is known as either a guitar dyad or a double stop. They definitely make your solos or rhythm playing dynamic and more interesting. I cover the main intervals that you will see in popular music genres used as dyads, provide some interval guitar shapes for them, and end with some TAB examples for C, A, and E chords.



Guitar dyads & guitar intervals

All the common guitar dyads, also called double stops, are the most harmonious intervals from the major scale. If you do not know all the intervals, then check out my Music Intervals Article. The music intervals most often used for dyads are the ones that sound good – plain and simple.



Diatonic music intervals for guitar

The intervals for scales or chord involve some form of 2nds, 3rds, 4ths, 5ths, 6ths, 7ths, and octaves. When it comes to dyads, no one plays 2nds as far as I know, and rarely will you hear 7ths either. So that leaves 4 interval types.

In my opinion, the best double stops involve 3rds and 6ths, and I’m sure most other guitarists would agree. But 4ths and 5ths also sound good and don’t forget about octaves though those are a little trickier in include during fast licks.

The term “Country double stops” most often involves 6ths and they sound absolutely fantastic. I definitely love them more than 3rds. I also included some tritone shapes as well. For those and the 4th’s and 5ths, just focus on the bottom 2 notes in the interval shapes I included.

Guitar dyad or interval shapes

Here are some basic interval shapes for the guitar on the highest sets of strings. But check out the music intervals article I mention above for full coverage on the topic.

By the way, “M” is for major, “m” for minor, “P” for perfect (as in 4ths and 5ths) and the tritone is either an augmented 4th (A4) or diminished 5th (d5). For example, “m6” stands for minor 6th interval.



major 3rd guitar dyad G string root
major 3rd double stop B string root
minor 3rd guitar dyad G string root
minor 3rd double stop B string root



major 6th guitar dyad D string root
major 6th double stop G string root
major 6th guitar dyad D string root
major 6th double stop G string root



Perfect 4th dyad A and G string root
Perfect fourth double stop D and B string root
Tritone music interval D string root
Tritone music interval G string root



perfect 5th interval D string root
octave interval D string
octave interval G string





Guitar double stop TAB examples

Here are some basic examples I whipped up in Guitar Pro. Make sure to come up with your own so that you fully understand how to use them.

The first TAB example has the classic Jimi Hendrix major pentatonic licks in C major. Disregard the “T” which is normally for tapping. Guitar Pro has that as a hammer-on option and I selected it instead of regular hammer-ons.

Classic major pentatonic dyads for guitar



This net TAB has various A major pentatonic licks but is best suited for A blues or as the V7 chord in D major IMO. Try them for yourself.

Guitar dyads good over A major

The final tab is in E and also good for E blues (1st 2 measures) or A major going from E7 > D (last 2 measures).

E double stops guitar TAB



Also, give a listen to The Wind Cries Mary by Jimi Hendrix for major pentatonic guitar dyads. I personally like the tritone in a 7th chord where you hammer from the M3 to the P4 repeatedly, e.g. over a C7 try Bb-E to F-Bb on the 5th and 6ths frets of the E and B strings.

Check out these sources for more on guitar dyads:

Red Hot Country Guitar by Michael Hawley – there is a section on double stops (also available on Amazon)

Hot Country Guitar by Dave Rubin – Little Sister by Dwight Yoakum has nice double stops though the book is hard to find.

25 Great Country Guitar Solos by Dave Rubin – the last 2 songs have some nice guitar dyads: 1) The Claw, Jerry Donahue; 2) The World, Bad Paisley (also on Amazon)



Final Thoughts

We’re getting there. This is the latest in guitar techniques that should get your creative juices flowing. If you get stuck playing single notes then try some guitar dyads for inspiration and an alternative approach to soloing.
